GENISTA 100 120GNS.4-I1191
Bollard head with a diameter of 140mm.
Bollard height : 300mm.
Protection rating against dust and moisture: IP66 – full protection.
Protection rating for resistance against harmful mechanical impacts: IK06.
Die-cast aluminium body and top cover made of die-cast aluminium and extruded aluminium tube coated with polyester powder along with C4 treatment for corrosion resistance to guarantee further durability. Textured paint finish. Different RAL colour finishes available under request. C5-M special coating for highly corrosive environments is available under request.
7mm opal borosilicate glass.
White painted interior reflector to control the light and to create specific results.
A4 stainless steel locking screw. Optional supply of A2 stainless steel vandal-resistant screw.
Silicone gasket.
Anticondensation device.
PCB on the top of the fixture.
Built-in driver included. Ambient temperature: up to 50ºC.
Electronic options for light control : DALI.
Pre-wiring with 25cm of 3x1mm2 cable.
Double cable gland entry for installation in series.
IP68 connector not included, it can be ordered separately: F3.A3 (On/Off) / F3.A5 (DALI).
Mounting base supplied with the fixture.
Accessory for concrete installation reference F3.P1.BLD
Accessory for grass installation reference F3.O1.BLD
Leuchten Lichtstrom: 1309lm
Leuchten Anschlussleistung: 12.9 W
Leuchten Lichtausbeute: 101 lm/W
Lichtquelle Lichtstrom: 1984lm
Lichtquelle Watt: 11.53 W
mA: 350 mA
Ähnlichste Farbtemperatu: 3000K
Farborttoleranz: MacAdam 3
CRI: 80
Winkel: 360
Photobiologisches Risiko: 1
Dieses Produkt enthält eine Lichtquelle der Energieeffizienzklasse: C
Mittlere Bemessungslebensdauer: >72.000h L80B10
Klasse: 1
IP: 66
IK: IK06
Glühdraht: 850
Außendurchmesser: 140mm
Gewicht: 3.56 Kg
Elektronisches Zubehör:
S: On/Off
-
7: RAL9006: Weißaluminium -
4: RAL7016: Anthrazitgrau -
2: RAL9005: Tiefschwarz -
1: RAL9010: Reinweiß
Todos los colores RAL están disponibles bajo pedido.
