COLUTEA 500 520CLX.4-I1204
Cylindrical design with a diameter of 110mm.
Luminaire height: 300mm.
Protection rating against dust and moisture: IP66 – full protection.
Protection rating for resistance against harmful mechanical impacts: IK10.
Die-cast aluminium body and top cover made of die-cast aluminium coated with polyester powder along with C4 treatment for corrosion resistance to guarantee further durability. Textured paint finish. Different RAL colour finishes available under request. C5-M special coating for highly corrosive environments is available under request.
7mm opal borosilicate glass.
Aluminium disks to get specific photometric results and to increase visual comfort.
A4 stainless steel locking screw. Optional supply of A2 stainless steel vandal-resistant screw.
Silicone gasket.
Anticondensation device.
PCB on the top of the fixture.
Built-in driver included.
Electronic options for light control: DALI-2.
The driver contained in this luminaire complies with European Directive 2009/125/EC establishing flicker limits: PstLM ≤ 1 and SVM ≤ 0.4.
Pre-wiring with 25cm of 3x1mm2 cable.
Double cable gland entry for installation in series.
IP68 connector not included, it can be ordered separately: F3.A3 (On/Off) / F3.A5 (DALI).
Mounting to the wall through mounting plate with two fixing holes. Cable entry from the mounting plate.
Leuchten Lichtstrom: 208lm
Leuchten Anschlussleistung: 9.18 W
Leuchten Lichtausbeute: 23 lm/W
Lichtquelle Lichtstrom: 1485lm
Lichtquelle Watt: 8.27 W
mA: 250 mA
Ähnlichste Farbtemperatu: 4000K
Farborttoleranz: MacAdam 3
CRI: 80
Winkel: 360
Photobiologisches Risiko: 1
Dieses Produkt enthält eine Lichtquelle der Energieeffizienzklasse: C
Mittlere Bemessungslebensdauer: L80B10 >72.000h
Klasse: 1
IP: 66
IK: IK10
Glühdraht: 850
Außendurchmesser: 110mm
Elektronisches Zubehör:
S: On/Off (AC/DC)
D: DALI-2/switchDIM/corridorFUNCTION
B: Bluetooth-Casambi [ 5m ]
-
7: RAL9006: Weißaluminium -
4: RAL7016: Anthrazitgrau -
2: RAL9005: Tiefschwarz -
1: RAL9010: Reinweiß
Todos los colores RAL están disponibles bajo pedido.
