GENISTA 200

GENISTA 200


Bollard with 360º light emission, radial beam.
Bollard head with a diameter of 140mm.
Available in 4 heights.
Protection rating against dust and moisture: IP66 – full protection.
Protection rating for resistance against harmful mechanical impacts: IK06 or IK10 diffuser.
Die-cast aluminium body and top cover treated for corrosion resistance (nanophoresis) and covered with a polyester powder coating to guarantee durability. Textured paint finish.
Special coating for environments with very high corrosivity is available under request.
Extruded aluminium tube with corrosion resistance treatment and finish according to the head finish.
7mm clear borosilicate glass or 5mm clear extruded polycarbonate diffuser made by resins UV rays stabilized.
White painted interior reflector to control the light and to create specific results.
Silicone gasket.
Anticondensation device.
PCB on the top of the fixture.
Built-in driver included.
Electronic options for light control : DALI.
Pre-wiring with 25cm of 3x1mm2 cable.
Double cable gland entry for installation in series.
IP68 connector not included, it can be ordered separately.

Product configurator

Tilt

Fixture diameter

Height

IK

Colour Temperature

CRI

UGR

Beam angle

Diffuser

Accessories

Electronic equipment

Search results
Beam angle
Reference
Watt
Luminous flux of the luminaire
CRI
Colour Temperature
Fixture diameter
Height

F220GNX_230GNX
360
4.84W
439lm
80
3000K
110
239
240GNX.4-I1197
DATA SHEET
Photometric IES
Technical drawing
Photometric LDT


F220GNX_230GNX
360
4.84W
473lm
80
4000K
110
239
240GNX.4-I1198
DATA SHEET
Photometric IES
Technical drawing
Photometric LDT


F220GNX_230GNX
360
6.53W
582lm
80
3000K
110
239
240GNX.4-I1200
DATA SHEET
Photometric IES
Technical drawing
Photometric LDT


F220GNX_230GNX
360
6.53W
624lm
80
4000K
110
239
240GNX.4-I1201
DATA SHEET
Photometric IES
Technical drawing
Photometric LDT


F220GNX_230GNX
360
8.27W
718lm
80
3000K
110
239
240GNX.4-I1203
DATA SHEET
Photometric IES
Technical drawing
Photometric LDT


F220GNX_230GNX
360
8.27W
772lm
80
4000K
110
239
240GNX.4-I1204
DATA SHEET
Photometric IES
Technical drawing
Photometric LDT


F222GNX_232GNX
360
4.84W
439lm
80
3000K
110
439
242GNX.4-I1197
DATA SHEET
Photometric IES
Technical drawing
Photometric LDT


F222GNX_232GNX
360
4.84W
473lm
80
4000K
110
439
242GNX.4-I1198
DATA SHEET
Photometric IES
Technical drawing
Photometric LDT


F222GNX_232GNX
360
6.53W
582lm
80
3000K
110
439
242GNX.4-I1200
DATA SHEET
Photometric IES
Technical drawing
Photometric LDT


F222GNX_232GNX
360
6.53W
624lm
80
4000K
110
439
242GNX.4-I1201
DATA SHEET
Photometric IES
Technical drawing
Photometric LDT


F222GNX_232GNX
360
8.27W
718lm
80
3000K
110
439
242GNX.4-I1203
DATA SHEET
Photometric IES
Technical drawing
Photometric LDT


F222GNX_232GNX
360
8.27W
772lm
80
4000K
110
439
242GNX.4-I1204
DATA SHEET
Photometric IES
Technical drawing
Photometric LDT


F220GNX_230GNX
360
4.84W
439lm
80
3000K
110
239
250GNX.4-I1197
DATA SHEET
Photometric IES
Technical drawing
Photometric LDT


F220GNX_230GNX
360
4.84W
473lm
80
4000K
110
239
250GNX.4-I1198
DATA SHEET
Photometric IES
Technical drawing
Photometric LDT


F220GNX_230GNX
360
6.53W
582lm
80
3000K
110
239
250GNX.4-I1200
DATA SHEET
Photometric IES
Technical drawing
Photometric LDT
