120UND.4-I1190
120UND
120UND.4-I1190
120UND.4-I1190

UNEDO 100



120UND.4-I1190


Bollard with 360º light emission, radial beam.
Bollard head with a diameter of 140mm.
Bollard height : 300mm.
Protection rating against dust and moisture: IP66 – full protection.
Protection rating for resistance against harmful mechanical impacts: IK06.
Die-cast aluminium body and top cover made of die-cast aluminium and extruded aluminium tube coated with polyester powder along with C4 treatment for corrosion resistance to guarantee further durability. Textured paint finish. Different RAL colour finishes available under request. C5-M special coating for highly corrosive environments is available under request.
7mm opal borosilicate glass.
A4 stainless steel locking screw. Optional supply of A2 stainless steel vandal-resistant screw.
Silicone gasket.
Anticondensation device.
PCB on the top of the fixture.
Built-in driver included. Ambient temperature: up to 50ºC.
Electronic options for light control : DALI.
Pre-wiring with 25cm of 3x1mm2 cable.
Double cable gland entry for installation in series.
IP68 connector not included, it can be ordered separately: F3.A3 (On/Off) / F3.A5 (DALI) Mounting base supplied with the fixture.
Accessory for installation in concrete reference F3.P1.BLD
Accessory for installation in grass reference F3.O1.BLD

Lichtquelle Lichtstrom: 1553lm

Leuchten Lichtstrom:  683lm

Leuchten Lichtausbeute: 53 lm/W

Lichtquelle Watt: 11.53 W

Leuchten Watt: 12.9 W

mA: 350 mA

Ähnlichste Farbtemperatu: 2700K

Farborttoleranz: MacAdam 3

Farbwiedergabeindex: 90

Winkel: 360

Groupe de sécurité Photobiologique: 1

Dieses Produkt enthält eine Lichtquelle der Energieeffizienzklasse: E

Mittlere Bemessungslebensdauer: >72.000h L80B10

Klasse: 1

IP: 66

IK: IK06

Glühdraht: 850°

Außendurchmesser: 140

Gewicht: 3.56 Kg

Elektronische Ausrüstung:
S: On/Off
D: DALI-2

*Ein beliebiges vorgenanntes Suffix zur Referenz hinzufüge, um die gewünschte elektronische Ausrüstung anzugeben.

Erweiterbar, austauschbar, reparierbar

Reparability1 Reparability2

Marken

CE

ZUBEHÖR UND FINISHES

Standardausführungen

  • 4: RAL7016: Anthrazitgrau
  • 1: RAL9010: Reinweiß
  • 2: RAL9005: Tiefschwarz
  • 7: RAL9006: Weißaluminium

Weitere verfügbare Ausführungen
